Audio - Figure 8 Speaker Trurip (OFC)

Products

Audio - Figure 8 Speaker Cable (Standard)

Nexans ref. JSF2.0CL* (A or D) - Country ref. 3865

  • Conductor cross-section: 2 mm²
  • Nominal overall diameter: 3.4 x 7
  • Approximate weight: 0.05 kg/m
  • Stranding (No./mm): 64/0.20



Audio - Figure 8 Speaker Cable (Standard)

Nexans ref. JSF2.6CL1 - Country ref. 6563

  • Conductor cross-section: 2.6 mm²
  • Nominal overall diameter: 4.5 x 9
  • Approximate weight: 0.08 kg/m
  • Stranding (No./mm): 84/0.20



Description

Description

Standards

  • International
    Manufacturer specification

Application

Suitable for use in audio system for low and high power speaker connections.

Characteristics

Characteristics

Construction characteristics

Construction characteristics

Conductor material
Oxygen-free copper
Insulation
PVC

Dimensional characteristics

Dimensional characteristics

Number of cores
2

Electrical characteristics

Electrical characteristics

Maximum operating voltage
50 VAC / 120 VDC

Mechanical characteristics

Mechanical characteristics

Cable flexibility
Flexible

Usage characteristics

Usage characteristics

Packaging
Spool 100m
Maximum operating temperature
75 °C

Resources

Resources

Documentation

xls — 0 B
