PVC Flexible Trurip

Products

CU FLEX-TRP 2X0.75 WH V75 1HM

Nexans ref. JSF.75WT1 - Country ref. 8051

  • Packaging: Spool (100m)
  • Sheath colour: White



CU FLX-TRP 2X0.75 BK V75 1HM

Nexans ref. JSF.75BK1 - Country ref. 3899

  • Packaging: Spool (100m)
  • Sheath colour: Black



Description

Description

Standards

  • National
    AS/NZS 3191

Application

Flexible and easy to intall PVC sheath cables, ideal for domestic and commercial applications.

Note

Content from AS/NZS 3008.1.2:2010 has been reproduced with the permission from Standards New Zealand under Copyright Licence 00926.  Please see the standard for full details.

Characteristics

Characteristics

Construction characteristics

Construction characteristics

Insulation
PVC

Dimensional characteristics

Dimensional characteristics

Number of cores
2
Conductor cross-section
0.75 mm²
Nominal overall diameter
3.1 x 5.9
Approximate weight
0.03 kg/100m

Electrical characteristics

Electrical characteristics

Rated Voltage Uo/U
250/440 V
Voltage drop single phase at 45°C
60.2 mV/A.m

Usage characteristics

Usage characteristics

Maximum operating surface temperature
60 °C

Resources

Resources

Documentation

xls — 0 B
