Cu Aerial - Neutral Screen

Products

Cu Aerial - Neutral Screen 1 x 6mm2

Nexans ref. BAGT11AA001CXRD - Country ref. 2559

  • Pilot wires: None
  • Number of cores: 1
  • Conductor cross-section: 6 mm²
  • Nominal overall diameter: 10.1 mm
  • Approximate weight: 0.2 kg/m



Cu Aerial - Neutral Screen 1 x 16mm2

Nexans ref. BAGT15AA001CXRD - Country ref. 3481

  • Pilot wires: None
  • Number of cores: 1
  • Conductor cross-section: 16 mm²
  • Nominal overall diameter: 12.8 mm
  • Approximate weight: 0.41 kg/m



Cu Aerial - Neutral Screen 1 x 16mm2 + 1P2.5mm2

Nexans ref. QDAT15AA001CXRD - Country ref. 9643

  • Pilot wires: 2.5 mm²
  • Number of cores: 1
  • Conductor cross-section: 16 mm²
  • Nominal overall diameter: 19.5 mm
  • Approximate weight: 0.53 kg/m



Cu Aerial - Neutral Screen 2 x 16mm2

Nexans ref. DAET15AA002CXAB - Country ref. 6831

  • Pilot wires: None
  • Number of cores: 2
  • Conductor cross-section: 16 mm²
  • Nominal overall diameter: 19.6 mm
  • Approximate weight: 0.63 kg/m



Cu Aerial - Neutral Screen 2 x 16mm2 + 1P2.5mm2

Nexans ref. QDHT15AA002CXRD - Country ref. 8280

  • Pilot wires: 2.5 mm²
  • Number of cores: 2
  • Conductor cross-section: 16 mm²
  • Nominal overall diameter: 21.0 mm
  • Approximate weight: 0.78 kg/m



Cu Aerial - Neutral Screen 3 x 6mm2

Nexans ref. FAGT11AA003CXRJ - Country ref. 4674

  • Pilot wires: None
  • Number of cores: 3
  • Conductor cross-section: 6 mm²
  • Nominal overall diameter: 16.2 mm
  • Approximate weight: 0.43 kg/m



Cu Aerial - Neutral Screen 3 x 10mm2

Nexans ref. FAGT13AA003CXRJ - Country ref. 7695

  • Pilot wires: None
  • Number of cores: 3
  • Conductor cross-section: 10 mm²
  • Nominal overall diameter: 18.2 mm
  • Approximate weight: 0.59 kg/m



Cu Aerial - Neutral Screen 3 x 16mm2

Nexans ref. FAGT15AA003CXRJ - Country ref. 6234

  • Pilot wires: None
  • Number of cores: 3
  • Conductor cross-section: 16 mm²
  • Nominal overall diameter: 20.7 mm
  • Approximate weight: 0.87 kg/m



Cu Aerial - Neutral Screen 3 x 16mm2 + 1P2.5mm2

Nexans ref. QDHT15AA003CXRJ - Country ref. 3771

  • Pilot wires: 2.5 mm²
  • Number of cores: 3
  • Conductor cross-section: 16 mm²
  • Nominal overall diameter: 22.8 mm
  • Approximate weight: 0.99 kg/m



Description

Description

Standards

  • National
    AS/NZS 4961

Can be used for aerial reticulation to residential and rural areas where reliability, safety and low installation costs are required.

It is also designed for residential and rural areas for reducing the bushfire hazards.

The covering contains a high level of carbon black for UV resistance.

It is designed for where reliability, safety and low installation costs are required, but it is only for short spans due to increased weight.

Note

  1. Content from AS/NZS 3008.1.2:2010 has been reproduced with the permission from Standards New Zealand under Copyright Licence 000926. Please see the Standard for full details.
  2. Current ratings are based on an ambient temperature of 30°C, a maximum conductor temperature of 75°C, summer noon and intensity of solar radiation 1000 W/m².

Characteristics

Characteristics

Construction characteristics

Construction characteristics

Conductor material
Copper
Insulation
PVC
Screen
Copper wire
Outer sheath
PVC

Electrical characteristics

Electrical characteristics

Rated Voltage Uo/U (Um)
0.6/ 1 (1.2) kV

Usage characteristics

Usage characteristics

Maximum operating temperature
75 °C
